D-Link Layer 2 Gigabit Managed Long Range PoE+ Surveillance Switch (DGS-F1210-18PS-E)
| Dimensions | 44 × 18 × 4.4 cm |
|---|---|
| Condition | Brand New |
| Color | Black |
| No. of LAN Ports | 2 Gigabit SFP Ports , 16 LAN Ports |
| Network Interface | Integrated 10/100/1000 GbE LAN |
| Supported Standards | IEEE802.3z 1000 BASE-X , IEEE 802.3 10BASE-T Ethernet , IEEE 802.3u 100BASE-TX Fast Ethernet , IEEE 802.3ab 1000BASE-T Gigabit Ethernet , ANSI/IEEE 802.3 NWay auto-negotiation , IEEE 802.3x Flow Control , IEEE 802.3af , IEEE 802.3at |
| Network Cables | 1000BASE-T: EIA/TIA-568 100-ohm STP (100 m max) , 1000BASE-T: UTP CAT 5/5e (100 m max) , 100BASE-TX: EIA/TIA-568 100-ohm STP (100 m max) , 100BASE-TX: UTP CAT 5/5e (100 m max) , 10BASE-T: EIA/TIA-586 100-ohm STP (100 m max) , 10BASE-T: UTP CAT 3 , 4 , 5/5e (100 m max) |
| Configuration | Plug n' Play |
| MAC Address Table | 8K |
| Transfer Rates | Ethernet: 10 Mbps (Half Duplex) , Fast Ethernet: 100 Mbps (Half Duplex) , Ethernet: 20 Mbps (Full Duplex) , Fast Ethernet: 200 Mbps (Full Duplex) , Gigabit Ethernet: 1000 Mbps |
| Trans. Method Transmission method. | Store-and-forward |
| MAC Address Learning | Automatic Update |
| Switching Capacity | 36 Gbps |
| Port Packet Filtering | 10M: 14 , 880 pps , 100M: 148 , 800 pps , 1000M: 1 , 488 , 000 pps |
| LED Indicators | Link/Activity Indicator , Power Indicator , Speed LEDs , PoE |
| Voltage | 100 to 240 Volts |
| Add. Features Additional Features. | Green Ethernet , Full/half-duplex for Ethernet/Fast Ethernet speeds , IEEE 802.3x Flow Control , RoHS compliant , IEEE 802.3az Energy Efficient Ethernet (EEE) |
| Storage Temperature | 14 to 158 °F (-10 to 70 °C) |
| Storage Humidity | 10%~90% non-condensing |
| Operating Temperature | 0℃~40℃ (32℉~104℉) |
| Operating Humidity | 10%~90% non-condensing |
| Warranty | 12 Months Warranty |
D-Link 24-Port Gigabit Unmanaged Desktop Switch (DGS-1024C)
| Dimensions | 17.8 × 28 × 4.4 cm |
|---|---|
| Condition | Brand New |
| Color | Black |
| No. of LAN Ports | 24 LAN Ports |
| Network Interface | Integrated 10/100/1000 GbE LAN |
| Supported Standards | IEEE 802.3 10BASE-T Ethernet , IEEE 802.3u 100BASE-TX Fast Ethernet , IEEE 802.3ab 1000BASE-T Gigabit Ethernet , ANSI/IEEE 802.3 NWay auto-negotiation , IEEE 802.3x Flow Control , IEEE 802.1p QoS |
| Network Cables | 1000BASE-T: EIA/TIA-568 100-ohm STP (100 m max) , 1000BASE-T: UTP CAT 5/5e (100 m max) , 100BASE-TX: EIA/TIA-568 100-ohm STP (100 m max) , 100BASE-TX: UTP CAT 5/5e (100 m max) , 10BASE-T: EIA/TIA-586 100-ohm STP (100 m max) , 10BASE-T: UTP CAT 3 , 4 , 5/5e (100 m max) |
| Configuration | Plug n' Play |
| MAC Address Table | 8K |
| Transfer Rates | Ethernet: 10 Mbps (Half Duplex) , Fast Ethernet: 100 Mbps (Half Duplex) , Ethernet: 20 Mbps (Full Duplex) , Fast Ethernet: 200 Mbps (Full Duplex) , Gigabit Ethernet: 2000 Mbps (Full Duplex) |
| Trans. Method Transmission method. | Store-and-forward |
| MAC Address Learning | Automatic Update |
| Jumbo Frames | 9216 Bytes |
| RAM Buffer | 512 KB per device |
| Switching Capacity | 48 Gbps |
| Port Packet Filtering | 10M: 14 , 880 pps , 100M: 148 , 800 pps , 1000M: 1 , 488 , 000 pps |
| LED Indicators | Link/Activity Indicator , Power Indicator , Speed LEDs |
| Voltage | 100 to 240 Volts |
| Add. Features Additional Features. | Green Ethernet , Full/half-duplex for Ethernet/Fast Ethernet speeds , IEEE 802.3x Flow Control , RoHS compliant , IEEE 802.3az Energy Efficient Ethernet (EEE) , Link status detection power saving , Cable length detection power saving |
| Storage Temperature | 14 to 158 °F (-10 to 70 °C) |
| Storage Humidity | 5% to 90% non-condensing |
| Operating Temperature | 0℃~40℃ (32℉~104℉) |
| Operating Humidity | 5% to 90% non-condensing |
| Warranty | 12 Months Warranty |
D-Link 8GE PoE+ 2GE Uplink 250m PoE Switch (DGS-1010P-E)
| Dimensions | 18.4 × 7.5 × 2.7 cm |
|---|---|
| Condition | Brand New |
| Color | Black |
| No. of LAN Ports | 2 Uplink LAN Ports , 8 LAN Ports |
| Network Interface | Integrated 10/100/1000 GbE LAN |
| Supported Standards | IEEE 802.3 10BASE-T Ethernet , IEEE 802.3u 100BASE-TX Fast Ethernet , ANSI/IEEE 802.3 NWay auto-negotiation , IEEE 802.3x Flow Control , IEEE 802.3af , IEEE 802.3at |
| Network Cables | 1000BASE-T: EIA/TIA-568 100-ohm STP (100 m max) , 1000BASE-T: UTP CAT 5/5e (100 m max) , 100BASE-TX: EIA/TIA-568 100-ohm STP (100 m max) , 100BASE-TX: UTP CAT 5/5e (100 m max) , 10BASE-T: EIA/TIA-586 100-ohm STP (100 m max) , 10BASE-T: UTP CAT 3 , 4 , 5/5e (100 m max) |
| Configuration | Plug n' Play |
| Transfer Rates | Fast Ethernet: 100 Mbps (Half Duplex) , Gigabit Ethernet: 1000 Mbps |
| Trans. Method Transmission method. | Store-and-forward |
| MAC Address Learning | Automatic Update |
| Switching Capacity | 20 Gbps |
| Port Packet Filtering | 10M: 14 , 880 pps , 100M: 148 , 800 pps , 1000M: 1 , 488 , 000 pps |
| LED Indicators | Link/Activity Indicator , Power Indicator |
| Add. Features Additional Features. | Green Ethernet , IEEE 802.3x Flow Control , RoHS compliant , IEEE 802.3az Energy Efficient Ethernet (EEE) |
| Storage Temperature | 14 to 158 °F (-10 to 70 °C) |
| Storage Humidity | 0% ~ 95% non-condensing |
| Operating Temperature | 0℃~40℃ (32℉~104℉) |
| Operating Humidity | 0% ~ 95% non-condensing |
| Warranty | 12 Months Warranty |
D-Link 8-Port Gigabit Easy Desktop Switch (DGS-1008A)
| Dimensions | 7.85 × 14.15 × 2.38 cm |
|---|---|
| Color | White |
| Condition | Brand New |
| No. of LAN Ports | 8 LAN Ports |
| Network Interface | Integrated 10/100/1000 GbE LAN |
| Supported Standards | IEEE 802.3 10BASE-T Ethernet , IEEE 802.3u 100BASE-TX Fast Ethernet , IEEE 802.3x Flow Control , IEEE 802.1p QoS , IEEE 802.3az Energy-Efficient Ethernet (EEE) |
| Network Cables | 100BASE-TX: EIA/TIA-568 100-ohm STP (100 m max) , 100BASE-TX: UTP CAT 5/5e (100 m max) , 10BASE-T: EIA/TIA-586 100-ohm STP (100 m max) , 10BASE-T: UTP CAT 3 , 4 , 5/5e (100 m max) |
| MAC Address Table | 4K |
| Transfer Rates | Ethernet: 10 Mbps (Half Duplex) , Fast Ethernet: 100 Mbps (Half Duplex) , Ethernet: 20 Mbps (Full Duplex) , Fast Ethernet: 200 Mbps (Full Duplex) |
| Trans. Method Transmission method. | Store-and-forward |
| MAC Address Learning | Automatic Update |
| Jumbo Frames | 9720 Bytes |
| RAM Buffer | 192 KB per device |
| Switching Capacity | 16 Gbps |
| Port Packet Filtering | 10M: 14 , 880 pps , 100M: 148 , 800 pps |
| LED Indicators | Link/Activity Indicator , Power Indicator |
| Voltage | 5 Volts |
| Add. Features Additional Features. | Green Ethernet , Auto MDI/MDIX crossover for all ports , Secure store-and-forward switching scheme , Compliance with IEEE802.3az EEE power saving , IEEE 802.3x Flow Control , RoHS compliant |
| Storage Temperature | -10 to 70 °C (14 to 158 °F) |
| Storage Humidity | 5%~90% non-condensing |
| Operating Temperature | 0 to 40 °C (32 to 104 °F) |
| Operating Humidity | 5% to 90% non-condensing |
| Warranty | 12 Months Warranty |
